Solar irradiance is a core environmental parameter that determines the power generation efficiency of photovoltaic modules. Accurately measuring total radiation, scattered radiation, and effective irradiance of module planes is crucial for site selection evaluation, system design, power generation prediction, efficiency analysis, and fault diagnosis of photovoltaic power plants. Traditional irradiation measurement equipment has a large volume, complex installation, and high cost, making it difficult to meet the needs of on-site mobile detection and multi-point flexible deployment. Jiangsu Jingwei Technology Co., Ltd. has launched the JW-F04 portable irradiance meter with its profound accumulation of optical sensing and precision measurement technology. With the advantages of high precision, portability, and intelligence, it provides an efficient and reliable domestic solution for photovoltaic system light energy measurement. Portable irradiation system dosimeter
JW-F04 is a high-precision measurement device specially developed for photovoltaic system light energy assessment and environmental monitoring. Its core is used for synchronous and accurate measurement of total solar irradiance, scattered radiation, reflected radiation, and effective irradiance of component planes. It captures real-time dynamic changes in light energy resources and provides core environmental data for photovoltaic station performance evaluation and operation decision-making. The equipment adopts a secondary standard spectral response sensor and multi-channel optical detection technology, with high spectral matching and excellent angle characteristics. Combined with precise cosine correction, it can effectively eliminate angle errors and ensure measurement accuracy at different solar altitude angles. The data reliability reaches the industry standard level.
In terms of functional design, JW-F04 fully meets the requirements of photovoltaic full scenario applications. The instrument can independently measure total radiation and scattered radiation, and can also be used in conjunction with component planar probes to accurately measure the effective radiation received by the component, which can be directly used to calculate component conversion efficiency and system efficiency; Support multi-point mobile detection, fixed-point long-term monitoring, adapt to scenarios such as power station site selection survey, design verification, completion acceptance, operation and maintenance inspection, scientific research experiments, etc., and flexibly meet the data needs of different stages. Built in intelligent calibration algorithm, supporting one click calibration and automatic temperature compensation, effectively reducing the impact of environmental temperature changes on measurement accuracy and ensuring long-term stability.
Portability and ease of use are the prominent advantages of JW-F04. The whole machine adopts a lightweight integrated design, with small size and light weight, which can be carried by hand or in a portable case, and can be easily operated by a single person, especially suitable for outdoor mobile detection; The probe is designed to be separated from the host and can be flexibly arranged on the component plane or any measuring point, with convenient installation and strong adaptability. Equipped with a high-definition LCD display screen, it displays real-time measurement data, peak recording, temperature and other information. The interface is simple and intuitive, and the operation buttons are easy to understand, making it easy to get started without professional training.
Intelligent and data management capabilities enhance application efficiency. JW-F04 has built-in large capacity data storage, which can automatically record historical measurement data and support custom recording of time intervals to meet long-term monitoring needs; Equipped with USB data export and wireless transmission functions, data can be exported to a computer or uploaded to a cloud platform for easy data organization, trend analysis, and report generation; Equipped with professional analysis software, it can achieve functions such as data visualization, radiation resource evaluation, and power generation simulation calculation, providing data support for optimizing photovoltaic systems.
Strict environmental adaptability and reliability design. JW-F04 adopts industrial grade protective shell, which is dustproof, moisture-proof, and UV resistant. It can work stably in extreme temperature environments ranging from -30 ℃ to 70 ℃ and adapt to harsh outdoor conditions such as deserts, coasts, and high altitudes; The sensor has undergone strict screening and aging testing, with good stability, long lifespan, and long-term use without frequent calibration, reducing maintenance costs. The equipment complies with international and national standards such as IEC60904 and GB/T19565, and the measurement data can be used as a third-party measurement basis, with strong authority.
Jiangsu Jingwei Technology is deeply engaged in the field of photovoltaic detection and environmental monitoring, adhering to independent innovation. The technical team has many years of experience in optical sensing and precision measurement research and development. The core sensors and algorithms of the JW-F04 portable irradiance meter are all domestically developed, breaking the monopoly of foreign brands and reaching the international level of similar products in key indicators such as measurement accuracy, stability, and portability. At the same time, it has higher cost-effectiveness and localized service advantages. The company provides one-stop support for technical training, calibration services, and after-sales maintenance to ensure the long-term stable operation of user equipment.
Under the trend of refined operation and digital transformation of photovoltaic power plants, accurate irradiation data is the foundation of scientific decision-making. The Jiangsu Jingwei JW-F04 portable irradiance meter provides reliable light energy measurement solutions for the entire life cycle of photovoltaic power plants with core advantages of high-precision measurement, strong environmental adaptability, portability and efficient, and intelligent data management. It helps the photovoltaic industry increase power generation, reduce electricity costs, achieve efficient and sustainable development, and injects new momentum into the development of China's new energy industry.
